Oscillators

Oscillators

HM International produce oscillators in a wide range of packages and output types including HCMOS, True Sinewave , LVPECL , HCSL and LVDS. Delivery leadtimes are short, even for production quantity requirements.

Picture Product Features Dimensions (mm) Frequency Range
sx1c SX1C Smallest package 2.0 x 1.6 x 0.8 mm 1.0 – 80.0 MHz
sx2c SX2C Very small package 2.5 x 2.0 x 0.9 mm 0.156 – 133.0 MHz
sx2cb SX2CB Low voltage 2.5 x 2.0 x 0.9 mm 0.312 – 60.0 MHz
sx2cg SX2CG Tight temperature stability 2.5 x 2.0 x 0.9 mm 2.5 – 55.0 MHz
sx3c SX3C Most standard package 3.2 x 2.5 x 1.2 mm 25 kHz – 160.0 MHz
sx3cb SX3CB Low voltage 3.2 x 2.5 x 1.2 mm 0.312 – 60.0 MHz
 sx3cl SX3CL Very low current 3.2 x 2.5 x 1.2 mm 0.5 – 50 MHz
sx3cg SX3CG Tight temperature stability 3.2 x 2.5 x 1.1 mm 2.5 – 55.0 MHz
sx3cj SX3CJ Ultra Low Jitter 3.2×2.5×1.1 mm 5.0 – 50.0 MHz
sx5c SX5C Most standard package 5.0 x 3.2 x 1.3 mm 25 kHz – 160.0 MHz
 sx5ca SX5CA Automotive Temperature range 5.0 x 3.2 x 1.3 mm 1.25 – 60.0 MHz
sx5cb SX5CB Low voltage 5.0 x 3.2 x 1.3 mm 0.312 – 60.0 MHz
sx5cl SX5CL Very low current 5.0 x 3.2 x 1.3 mm 0.5 – 50 MHz
sx5cg SX5CG Tight temperature stability 5.0 x 3.2 x 1.15 mm 2.5 – 55.0 MHz
sx5cj SX5CJ Ultra Low Jitter 5.0 x 3.2 x 1.3 mm 5.0 – 50.0 MHz
sx5cc SX5CC Two frequencies output 5.0 x 3.2 x 1.3 mm 1.0 – 200.0 MHz
sx7c SX7C Wide frequency range 7.0 x 5.0 x 1.5 mm 25 kHz – 165.0 MHz
 sx7ca SX7CA Automotive Temperature range 7.0 x 5.0 x 1.5 mm 1.25 – 60.0 MHz
sx7cb SX7CB Low voltage 7.0 x 5.0 x 1.5 mm 0.312 – 60.0 MHz
sx7cl SX7CL Very low current 7.0 x 5.0 x 1.5 mm 0.25 – 50.0 MHz
sx7cj SX7CJ Ultra low jitter 7.0 x 5.0 x 1.5 mm 5.0 – 50.0 MHz
sp1c SP1C Plastic J-lead package 14.0 x 9.8 x 4.7 mm 1.0 – 200.0 MHz
sp2c SP2C Wide frequency range 14.3 x 8.7 x 5.5mm 1.0 – 800.0 MHz
dlhc DLHC DIL package 12.7 x 12.7 x 5.08 mm
12.7 x 12.7 x 7.48 mm
1.0 – 200.0 MHz
dlc DLC DIL package 20.7 x 13.1 x 5.08 mm
20.7 x 13.1 x 7.48 mm
1.0 – 800.0 MHz
Picture Product Features Dimensions (mm) Frequency Range
sx3ek SX3EK Reduced jitter design 3.2 x 2.5 x 1.1 mm 10.0 MHz – 1450 MHz
 sx3ep SX3EP next-day-delivery 3.2X2.5X1.1MM 10.0 MHz – 1450 MHz
sx5ek SX5EK Reduced jitter design 5.0 x 3.2 x 1.3 mm 10.0 – 1450 MHz
 sx5ep SX5EP next-day-delivery 5.0 x 3.2 x 1.3 mm 10.0 MHz – 1450 MHz
sx7ek SX7EK Reduced jitter design 7.0 x 5.0 x 1.8 mm 10.0 – 1450 MHz
 sx7ep SX7EP next-day-delivery 7.0 x 5.0 x 1.8 mm 10.0 MHz – 1450 MHz
sx7eu SX7EU Ultra Low Jitter 7.0×5.0x1.8 mm 100 MHz – 2100 MHz
sp2e SP2E Very low jitter 14.3 x 8.7 x 5.5 mm 0.75 – 800 MHz
dle DLE Wide frequency range 20.7 x 13.1 x 5.08 mm
20.7 x 13.1 x 7.48 mm
0.75 – 800 MHz
Picture Product Features Dimensions (mm) Frequency Range
 sx3lk SX3LK Reduced jitter design 3.2 x 2.5 x 1.1 mm 10.0 – 1450 MHz
 sx3lp SX3LP next-day-delivery 3.2×2.5×1.1 mm 10.0 MHz – 1450 MHz
 sx5lk SX5LK Reduced jitter design 5.0 x 3.2 x 1.3 mm 10.0 – 1450 MHz
 sx5lp SX5LP next-day-delivery 5.0X3.2X1.3MM 10.0 MHz – 1450 MHz
 sx7lk SX7LK Reduced jitter design 7.0 x 5.0 x 1.8 mm 10.0 – 1450 MHz
 sx7lp SX7LP next-day-delivery 7.0X5.0X1.8MM 10.0 MHz – 1450 MHz
 sx7lu SX7LU Ultra low jitter 7.0 x 5.0 x 1.8 mm 100 MHz – 2100 MHz
 sp2l SP2L Very low jitter 14.3 x 8.7 x 5.5 mm 0.75 – 800 MHz
 dll DLL Wide frequency range 20.7 x 13.1 x 5.08 mm
20.7 x 13.1 x 7.48 mm
0.75 – 800 MHz
Picture Product Features Dimensions (mm) Frequency Range
 sx3hk SX3HK Excellent Phase Noise 3.2 x 2.5 x 1.1 mm 13.5 – 200 MHz
 sx5hk SX5HK Excellent Phase Noise 5.0 x 3.2 x 1.3 mm 13.5 – 200 MHz
 sx7hk SX7HK Excellent Phase Noise 7.0 x 5.0 x 1.8 mm 13.5 – 200 MHz
Picture Product Features Dimensions (mm) Frequency Range
 sx3ssf SX3SSF 1.8V supply 3.2 x 2.5 x 1.1 mm 12.5 – 42.0 MHz
 sx5ssf SX5SSF 1.8V supply 5.0 x 3.2 x 1.3 mm 12.5 – 42.0 MHz
 sx5ss SX5SS Low EMI 5.0 x 3.2 x 1.3 mm 6.0 – 200 MHz
 sx5ssp SX5SSP next-day-delivery 5.0×3.2×1.3mm 3.0 MHz – 200 MHz
 sx7ssf SX7SSF 1.8V supply 7.0 x 5.0 x 1.6 mm 12.5 – 42.0 MHz
 sx7ss SX7SS Low EMI 7.0 x 5.0 x 1.8 mm 3.5 – 220 MHz
 sx7ssp SX7SSP next-day-delivery 7.0×5.0x1.6mm 3.0 MHz – 200 MHz
Picture Product Features Dimensions (mm) Frequency Range
 sx5sr SX5SR True Sine Wave 5.0 x 3.2 x 1.3 mm 10 – 30 MHz
 sx7sr SX7SR True Sine Wave 7.0 x 5.0 x 1.8 mm 10 – 30 MHz
 sp5sr SP5SR True Sine Wave 11.4 x 9.6 x 2.5 mm 10 – 30 MHz
 dls DLS Wide frequency range 20.4 x 12.9 x 5.08 mm 10 – 800 MHz
Picture Product Features Dimensions (mm) Frequency Range
 sx2p SX2P next-day-delivery 2.5 x 2.0 x 0.9 mm 1.0 – 200.0 MHz
 sx3p SX3P next-day-delivery 3.2 x 2.5 x 1.2 mm 1.0 – 200.0 MHz
 sx5p SX5P next-day-delivery 5.0 x 3.2 x 1.3 mm 1.0 – 200.0 MHz
 sx7p SX7P next-day-delivery 7.0 x 5.0 x 1.5 mm 1.0 – 200.0 MHz
Picture Product Features Dimensions (mm) Frequency Range
 sx2k SX2K AT-cut divider 2.5 x 2.0 x 0.9 mm 32.768 kHz
 sx2kl SX2KL AT-cut, Low current 2.5 x 2.0 x 0.9 mm 32.768 kHz
 sx3k SX3K AT-cut divider 3.2 x 2.5 x 1.2 mm 32.768 kHz
 sx3kl SX3KL AT-cut, Low current 3.2 x 2.5 x 1.2 mm 32.768 kHz
 sx3kf SX3KF Tuning-fork design 3.2 x 2.5 x 1.2 mm 32.768 kHz
 sx5k SX5K AT-cut divider 5.0 x 3.2 x 1.3 mm 32.768 kHz
 sx5kl SX5KL AT-cut , Low current 5.0 x 3.2 x 1.3 mm 32.768 kHz
 sx7k SX7K AT-cut divider 7.0 x 5.0 x 1.5 mm 32.768 kHz
 sx7kl SX7KL AT-cut , Low current 7.0 x 5.0 x 1.5 mm 32.768 kHz
